[CentOS]申請免費IPv6服務 at HE.net Tunnel
前陣子黑五買了VirMach超殺搶購的VPS 🐱🏍 但是都沒有IPv6，所以我把目光轉向Hurricane Electric提供的IPv6 Tunnel服務，HE.net在美國算是非常大的資料中心服務商了，穩定度還是可以相信滴，這邊留個筆記~🤖🤓🤖
申請方式
STEP1. 先到HE.net的IPv6 Tunnel服務申請一個帳號，然後進入左手邊的Create Regular Tunnel開始申請
STEP2. 在Create New Tunnel的頁面，IPv4 Endpoint (Your side):這個框框要輸入實際可連網的IP，Available Tunnel Servers就選擇地理位置靠近的地方，大致上就是選以下幾個地方吧。
- Los Angeles, CA, US 66.220.18.42
- Fremont, CA, US 72.52.104.74
- Fremont, CA, US 64.62.134.130
- Hong Kong, HK 216.218.221.6
- Singapore, SG 216.218.221.42
- Tokyo, JP 74.82.46.6
STEP3. 申請成功後，把Tunnel Details頁面列印出來或是轉存成pdf，然後記住此四項紀錄
- Server IPv4 Address: 72.52.104.74
- Client IPv4 Address: 107.172.xxx.xxx
- Client IPv6 Address: 2001:470:xxx:xxx::xxx/64
- Server IPv6 Address: 2001:470:1f04:1b7::1
SSH操作紀錄
### 啟用IPv6功能
|
1 2 3 4 5 6 |
echo 'net.ipv6.conf.all.disable_ipv6 = 0 net.ipv6.conf.default.disable_ipv6 = 0 net.ipv6.conf.lo.disable_ipv6 = 0' >> /etc/sysctl.conf cat /etc/sysctl.conf | grep ipv6 sudo sysctl --system sudo sysctl -p |
### 啟用IPv6網路支援
|
1 2 3 4 5 |
modprobe ipv6 sed -i '/IPV6_AUTOCONF/d' /etc/sysconfig/network sed -i '/NETWORKING_IPV6/d' /etc/sysconfig/network echo 'NETWORKING_IPV6=yes' >> /etc/sysconfig/network cat /etc/sysconfig/network | grep IPV6 |
### 設定IPv6通道的網路介面
IPV6TUNNELIPV4=【Server IPv4 Address】
IPV6TUNNELIPV4LOCAL=【Client IPv4 Address】
IPV6ADDR=”【Client IPv6 Address，加上/64】”
IPV6_DEFAULTGW=”【Server IPv6 Address，不要加上/64】”
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 |
cat <<"EOF" > /etc/sysconfig/network-scripts/ifcfg-heipv6 NAME="heipv6" DEVICE=heipv6 ONBOOT=yes USERCTL=yes BOOTPROTO=none PEERDNS=no <font color="#fef102">IPV6TUNNELIPV4=【Server IPv4 Address】</font> <font color="#e60000">IPV6TUNNELIPV4LOCAL=【Client IPv4 Address】</font> <font color="#00b300">IPV6ADDR="【Client IPv6 Address，加上/64】"</font> <font color="#1d9ceb">IPV6_DEFAULTGW="【Server IPv6 Address，不要加上/64】"</font> IPV6INIT=yes IPV6_AUTOTUNNEL=yes IPV6_ROUTER=yes IPV6_AUTOCONF=no IPV6_CONTROL_RADVD=yes PHYSDEV=eth0 TYPE=sit DEVICETYPE=sit NM_CONTROLLED=no IPV6_DEFAULTDEV=heipv6 EOF clear cat /etc/sysconfig/network-scripts/ifcfg-heipv6 |
### 重啟網路
|
1 |
systemctl restart network |
### 驗證IPv6網路狀況，有防火牆的可以暫停下來或是重開機試試看
# 透過內建的IP程式連線驗證gateway
|
1 |
/sbin/ip -6 route | grep -v ^unreachable | grep -v ^fe80 |
# 透過內建的IP程式連線驗證本機IP
|
1 |
/sbin/ip r get to 2001:4860:4860::8888 | perl -ne '/src ([\w:]+)/ && print "$1\n"' |
# 連線到icanhazip.com驗證本機IP
|
1 |
curl -6 icanhazip.com |
# 基本ping6、traceroute6測試
|
1 2 3 4 |
ping6 -c 1 ordns.he.net traceroute6 ordns.he.net ping6 -c 1 ipv6.google.com traceroute6 ipv6.google.com |
### 有時候會莫名其妙碰到下載IPV6很慢的狀況，此時可以使用此指令改用IPv4優先來解決
|
1 2 3 4 5 6 7 8 9 |
sed -i '/precedence/d' /etc/gai.conf sudo echo 'precedence ::ffff:0:0/96 100' >> /etc/gai.conf cat /etc/gai.conf sed -i '/prefer-family/d' /etc/wgetrc sudo echo 'prefer-family = IPv4' >> /etc/wgetrc cat /etc/wgetrc | grep prefer-family sed -i '/ipv4/d' ~/.curlrc sudo echo 'ipv4' >> ~/.curlrc cat ~/.curlrc |
ref.
